Drive Axle Forklift

Drive Axle for Forklifts - The piece of equipment that is elastically connected to the frame of the vehicle utilizing a lift mast is known as the lift truck drive axle. The lift mast affixes to the drive axle and can be inclined, by no less than one tilting cylinder, around the drive axle's axial centerline. Frontward bearing elements together with rear bearing parts of a torque bearing system are responsible for fastening the drive axle to the vehicle framework. The drive axle could be pivoted around a swiveling axis oriented transversely and horizontally in the vicinity of the rear bearing parts. The lift mast is also capable of being inclined relative to the drive axle. The tilting cylinder is attached to the vehicle frame and the lift mast in an articulated fashion. This allows the tilting cylinder to be oriented practically parallel to a plane extending from the swiveling axis to the axial centerline.

Model H40, H45 and H35 forklifts, that are produced by Linde AG in Aschaffenburg, Germany, have a attached lift mast tilt on the vehicle framework itself. The drive axle is elastically connected to the framework of the lift truck by numerous different bearings. The drive axle comprise tubular axle body together with extension arms connected to it and extend rearwards. This kind of drive axle is elastically affixed to the vehicle framework using rear bearing elements on the extension arms together with frontward bearing tools located on the axle body. There are two back and two front bearing tools. Each one is separated in the transverse direction of the vehicle from the other bearing device in its respective pair.

The drive and braking torques of the drive axle on tis particular unit of forklift are sustained utilizing the extension arms through the rear bearing elements on the framework. The forces created by the lift mast and the load being carried are transmitted into the floor or street by the vehicle framework through the front bearing components of the drive axle. It is essential to ensure the components of the drive axle are put together in a firm enough manner to maintain strength of the forklift truck. The bearing components can minimize minor road surface irregularities or bumps during travel to a limited extent and provide a bit smoother operation.
